Application of N-ZEO-SR Plus Fertilizer on the Dynamics of Lead (Pb) Heavy Metal in Soybean Plants (Glycine max L.)
Abstract
Lead (Pb) contamination in agricultural soil poses serious risks to crop productivity and food safety. This study investigated the effects of N-ZEO-SR Plus fertilizer dosage and Pb concentration on the growth and yield of soybean (Glycine max L.), as well as on Pb content in soil and seeds, and their interactions. A randomized block design (RBD) with two factors was employed: N-ZEO-SR Plus fertilizer dose (0, 50, 100, and 150 kg ha⁻¹) and Pb concentration (0, 50, and 100 ppm), with three replications. N-ZEO-SR Plus fertilizer significantly increased the number of leaves at 6 weeks after planting (WAP) (R² = 0.937, linear), chlorophyll content (optimum at 111.33 kg ha⁻¹, quadratic), and seed weight per plant, while significantly reducing soil Pb content (R² = 0.906, linear). Pb concentration significantly increased soil Pb content (R² = 0.957) and the percentage of Pb reduction (R² = 0.891), but did not affect growth or yield variables. Significant interactions between N-ZEO-SR Plus and Pb were observed for the number of filled pods, chlorophyll content, soil Pb content, and Pb reduction percentage. The interaction revealed competitive ion exchange at the highest combination (150 kg ha⁻¹ N-ZEO-SR Plus + 100 ppm Pb), where NH₄⁺ displaced adsorbed Pb²⁺ from zeolite exchange sites. All soybean seed samples exceeded the 0.5 ppm maximum permissible Pb limit (Permentan No. 53/2018), indicating that N-ZEO-SR Plus alone is insufficient to reduce seed Pb to safe levels. Moderate N-ZEO-SR Plus application (100 kg ha⁻¹) provided the best balance between growth enhancement and Pb immobilization.
Keywords
Download Options
Introduction
Soybean (Glycine max L.) is one of the most important leguminous crops in Indonesia, serving as a primary source of plant-based protein processed into tofu, tempeh, soy sauce, and soy milk [25]. However, soybean cultivation in Pb-contaminated soil raises concerns about food safety, as Pb can accumulate in plant tissues and enter the food chain [1, 16].
Lead (Pb) is a non-biodegradable toxic heavy metal that accumulates in soil and is readily absorbed by plant roots. Sources of Pb contamination include fertilizers, pesticides, industrial wastewater, mining waste, and vehicular emissions [4]. Pb inhibits plant growth by disrupting physiological processes such as photosynthesis, respiration, and nutrient absorption, ultimately leading to chlorosis, necrosis, reduced seed germination, and plant death [4]. Plants absorb Pb through roots and translocate it to stems, leaves, and seeds through three principal mechanisms: (1) root absorption, (2) translocation from roots to aerial parts, and (3) cellular localization [5].
Remediation of Pb-contaminated agricultural soil is essential for food security. Among various approaches, the use of zeolite-based slow-release fertilizers has shown promise. N-ZEO-SR Plus is a nitrogen fertilizer combining urea with nano-zeolite, nano-montmorillonite, nano-silicate, and humic substances [7]. Zeolite, a microporous aluminosilicate mineral with high cation exchange capacity (CEC) and large specific surface area, can adsorb Pb²⁺ ions through ion exchange and surface complexation [6]. In a slow-release fertilizer formulation, zeolite serves a dual function: regulating N release to improve nitrogen use efficiency, and immobilizing heavy metals through adsorption [2, 22].
Conclusion
1) N-ZEO-SR Plus fertilizer significantly increased the number of leaves at 6 WAP (linear, R² = 0.937), chlorophyll content (quadratic, optimum at 111.33 kg ha⁻¹), and seed weight per plant, while significantly reducing soil Pb content (linear, R² = 0.906).
2) Pb concentration (0–100 ppm) significantly increased soil Pb content (R² = 0.957) and Pb reduction percentage (R² = 0.891), but did not affect growth or yield, indicating that Deja-1 soybean can tolerate moderate Pb levels without visible toxicity.
3) Significant D×K interactions on the number of filled pods, chlorophyll content, soil Pb content, and Pb reduction percentage revealed that competitive ion exchange between NH₄⁺ and Pb²⁺ on zeolite sites can reduce chlorophyll and increase soil Pb at the highest combination (D3K2).
4) All soybean seed samples exceeded the 0.5 ppm maximum permissible Pb limit (Permentan No. 53/2018), indicating that N-ZEO-SR Plus alone is insufficient to reduce seed Pb to safe levels. Complementary remediation strategies such as phytoremediation, biochar amendment, or soil washing should be considered.
5) Moderate N-ZEO-SR Plus application (100 kg ha⁻¹) provides the best balance between enhancing soybean growth and immobilizing soil Pb, while avoiding negative interactions at higher Pb concentrations.
References
[1] Budiastuti, M. T. S., Syamsoeldak, R. D., & Paimin, B. (2016). Penapisan tanaman akumulator logam berat timbal (Pb) untuk fitoremediasi. Jurnal Tekno Hutan, *6*(2), 85-92.
[2] Chamidah, A., Mulyono, & Suharto, B. (2023). Pengaruh penambahan zeolit terhadap penurunan logam berat pada tanah. Jurnal Tanah dan Sumberdaya Lahan, *10*(1), 1-8.
[3] Emelda, A., Hanum, H., & Mukhlis. (2013). Pemanfaatan zeolit untuk mengadsorpsi logam berat pada tanah tercemar. Jurnal Online Agroekoteknologi, *1*(3), 895-904.
[4] Handayanto, E., Nuraini, Y., & Prijono, S. (2017). Logam berat pada tanah pertanian: Pencemaran dan remediasi. Jurnal Tanah dan Iklim, *41*(2), 121-130.
[5] Irawanto, R., Suharjo, B., & Pramono, A. (2015). Akumulasi logam berat timbal (Pb) pada tanaman di lahan pertanian. Jurnal Biologi, *4*(2), 55-62.
[6] Juliana, S., Suharto, B., & Rijzaani, H. (2015). Pengaruh zeolit sebagai adsorben logam berat Pb pada tanah. Jurnal Sumberdaya Alam, *5*(1), 21-26.
[7] Kharisun, Baskoro, D. P., & Widyati, E. (2017). Pengembangan pupuk nitrogen lepas lambat berbasis nano zeolit. Jurnal Tanah dan Iklim, *41*(1), 1-8.
[8] Lati, N., Suharjo, S., & Imran, A. M. (2023). Pengaruh nano zeolit dan pupuk organik terhadap ketersediaan Pb dan pertumbuhan padi pada tanah sulfat masam. Jurnal Tanah dan Sumberdaya Lahan, *10*(2), 231-242.
[9] Novandi, A. R., Sutrisno, & Haryati, N. (2014). Penyerapan logam berat Pb oleh tanaman pada tanah tercemar. Jurnal Tanah dan Lingkungan, *16*(1), 33-39.
[10] Pandey, S., Gupta, B., & Singh, R. (2022). The anatomical basis of heavy metal responses in legumes and their impact on plant–rhizosphere interactions. Plants, *11*(19), 1-18.
[11] Patti, P. S., Kaya, E., & Silahooy, C. (2013). Analisis status nitrogen tanah dalam kaitannya dengan serapan N oleh tanaman padi sawah di Desa Waimital. Agrologia, *2*(1), 51-58.
[12] Pramitasari, H. E., Wardiyati, T., & Nawawi, M. (2016). Pengaruh dosis pupuk nitrogen dan tingkat kepadatan tanaman terhadap pertumbuhan dan hasil tanaman kailan. Jurnal Produksi Tanaman, *4*(1), 49-56.
[13] Pratama, I., & Destiarti, N. L. (2018). Penurunan kadar timbal (II) menggunakan zeolit-X sintetis dari batu padas. Jurnal Kimia Khatulistiwa, *7*(1), 53-58.
[14] Pratomo, S. W., Mahatmanti, F. W., & Sulistyaningsih, T. (2017). Pemanfaatan zeolit alam teraktivasi H3PO4 sebagai adsorben ion logam Cd(II) dalam larutan. Indonesian Journal of Chemical Science, *6*(2), 161-167.
[15] Puspasari, R., Karyawati, A. S., & Sitompul, S. M. (2018). Pembentukan polong dan hasil tanaman kedelai dengan pemberian nitrogen pada fase generatif. Jurnal Produksi Tanaman, *6*(6), 1096-1102.
[16] Risalatuzain, E., Yosephin, B., & Okfrianti, Y. (2019). Identifikasi cemaran logam berat pada tempe di pengrajin tempe X dan Y Kota Bengkulu. Jurnal Media Kesehatan, *11*(2), 9-16.
[17] Rosidah, S., Anggraito, Y. U., & Pukan, K. K. (2014). Uji toleransi tanaman tembakau terhadap cekaman kadmium (Cd), timbal (Pb), dan tembaga (Cu) pada kultur cair. Life Science, *3*(2), 68-78.
[18] Santoso, F. J., Wahyudi, I., & Isrun, B. (2014). Evaluasi kandungan logam berat merkuri (Hg) pada beberapa tanaman pangan dan palawija di sekitar areal pengolahan tambang emas di Kelurahan Poboya, Kota Palu. e-Jurnal Agroteknologi, *2*(2), 138-145.
[19] Shen, Z., Jin, Y., Hou, D., & O'Connor, D. (2024). Biochar-zeolite composites for heavy metal immobilization in contaminated soils: Mechanisms and field applications. Science of the Total Environment, *912*, 1-18.
[20] Simanjuntak, P., Sihombing, P., & Simarmata, T. P. (2021). Respon pertumbuhan dan produksi tanaman kedelai terhadap pemberian dosis pupuk N dan pupuk kandang sapi. Majalah Ilmiah Methoda, *11*(1), 60-74.
[21] Sirenden, R. T., Anwar, M., & Damanik, Z. (2016). Pertumbuhan dan hasil tanaman kedelai yang diberi pupuk nitrogen dan molybdenum pada tanah podsolik merah kuning. Jurnal Agrium, *13*(2), 69-74.
[22] Sudirja, R., Joy, B., Rosniawaty, S., Setiawan, A., & Yunianto, R. I. (2016). Pengaruh formula pupuk urea-zeolit-arangaktif terhadap pH, N-total, KTK tanah dan residu Pb pada tanah tercemar limbah industri. Soilrens, *14*(1), 16-22.
[23] Sulastri, B. N., Apriyani, S., Zu'amah, H., Ardiwinata, A. N., & Purbalisa, W. (2021). Adsorption capacity of chelating agent to adsorb lead and arsenic. IOP Conference Series: Earth and Environmental Science, *648*(1), 1-9.
[24] Wang, Y., Li, X., Dong, H., & Ma, L. (2022). Zeolite amendment reduces Cd and Pb uptake in wheat under heavy metal stress: Effects on soil enzyme activities and microbial community. Environmental Science and Pollution Research, *29*, 42156-42169.
[25] Yuwariah, Y., Ruswandi, D., & Irwan, A. W. (2017). Pengaruh pola tanam tumpangsari jagung dan kedelai terhadap pertumbuhan dan hasil jagung hibrida dan evaluasi tumpangsari di Arjasari Kabupaten Bandung. Kultivasi, *16*(3), 515-521.
[26] Zainal, M., Nugroho, A., & Suminarti, N. E. (2014). Respon pertumbuhan dan hasil tanaman kedelai pada berbagai tingkat pemupukan N dan pupuk kandang ayam. Jurnal Produksi Tanaman, *2*(6), 484-490.
[27] Abebe, W. (2011). Identification and documentation of indigenous knowledge of beekeeping practices in selected districts of Ethiopia. Journal of Agricultural Extension and Rural Development, 3(5), 82–87.
