Macroscopic, Histological, and Ultrastructural Characterization of Cutaneous Papillomatosis in Buffaloes (Bubalus bubalis)

Authors: C.E.M.P.D.M. Cappellaro; M. H.B. Catroxo; A.M.C.R.P.F. Martins
Macroscopic, Histological, and Ultrastructural Characterization of Cutaneous Papillomatosis in Buffaloes (Bubalus bubalis)
DOI
10.25125/ijoear-sep-2026-27
DIN
IJOEAR-SEP-2026-27
Abstract

Macroscopic and microscopic observations were performed on papillomas located in the periauricular region of buffaloes (Bubalus bubalis), with comparison to the same anatomical region in buffaloes with normal skin. The macroscopic features of the papillomas in situ, as well as the microscopic features observed by light and electron microscopy, were described. The changes identified in the epidermal and dermal layers were predominantly proliferative, involved both regions, and supported a diagnosis of fibropapilloma. Degenerative changes were also observed in the epidermis, together with small virus-like particles located from the spinous layer toward the more superficial layers. Transmission electron microscopy also revealed areas of perinuclear degeneration, tonofibrils arranged around the nucleus and involved in the formation of intercellular bridges, melanin granules, and occasional cytoplasmic vacuoles. In these layers, in particular, osmiophilic virus-like particles were observed within the nucleus and in the intracytoplasmic spaces.

Keywords
buffalo skin papilloma cutaneous papillomatosis.
Download Options
Download Full PDF
Share Article
Facebook Twitter LinkedIn
Introduction

The buffalo Bubalus bubalis (LINNAEUS, 1758) was introduced into Brazil in 1890 from animals imported from the island of Trinidad to Marajó Island. Originating from the Asian continent, buffaloes were subsequently introduced into Europe, Oceania, and the Americas and are currently adapted to a wide variety of ecosystems worldwide (MARQUES & CARDOSO, 1997).

Buffaloes have productive aptitudes similar to those observed in cattle of European and Indian origin and can be used for milk and meat production and as draft animals. Although they are naturally more rustic, they have a high capacity for domestication, a process dating back to prehistoric times, particularly in regions of Indochina (MARQUES & CARDOSO, 1997).

Among the organs directly involved in the interaction between the organism and the environment, the skin stands out as one of the largest organs of the body and is responsible for covering the body surface. In addition to acting as a physical protective barrier against external agents, it performs several essential functions for maintaining organismal homeostasis. The skin consists of the epidermis, which is of ectodermal origin, and the dermis, which is of mesodermal origin. The epidermis is avascular, and its cells undergo progressive differentiation and keratinization, forming an important protective barrier against physical, chemical, and biological agents (JUNQUEIRA & CARNEIRO, 2013).

Warts or papillomas have long been recognized and described as disorders of the skin and mucous membranes of humans and animals. These growths are regarded as benign neoplastic lesions characterized primarily by the proliferative nature of the epithelium (FUJIMOTO & OLSON, 1966). The term papilloma came into use in the late nineteenth century to designate tumors formed by dermal papillae covered by epithelium (HELIAD, 1934). Over time, different forms of papillomatosis have been observed in several animal species, including horses and cattle, with variations in location and morphology related to the host and the type of virus involved (OLSON, 1963; LANCASTER & OLSON, 1982).

The etiology of papillomas was debated for many years. The viral nature of the disease began to be demonstrated in the early twentieth century, when CIUFFO (1907) described the existence of a filterable agent associated with human papillomas. Subsequently, MAGALHÃES (1920), working with bovine warts, demonstrated their viral origin by intradermal inoculation or skin scarification using cell-free filtrates obtained from papilloma suspensions. CREECH (1929) confirmed the infectivity of these filtrates, demonstrating that suspensions of bovine cutaneous papillomas were capable of reproducing the disease in healthy animals and that the resulting lesions could infect new animals.

The viral nature of papillomas was subsequently reinforced by experimental studies investigating their transmission, composition, and pathological changes in different settings (KOLLER & OLSON, 1972). In 1949, electron microscopy enabled visualization of virus-like particles in papillomas, associated with intranuclear inclusions arranged in crystalline patterns (STRAUSS et al., 1949). Other ultrastructural studies contributed to characterization of the viral particles and their relationship with epithelial cells (ALMEIDA et al., 1962; CHAPMAN et al., 1963). The papillomavirus genome was characterized as a circular double-stranded DNA molecule (FUJIMOTO & OLSON, 1966).

Papillomaviruses are small, non-enveloped viruses with an icosahedrally symmetrical capsid approximately 55–60 nm in diameter. The capsid consists of 72 capsomers corresponding to pentamers of the L1 structural protein and also contains the minor capsid protein L2. Within the capsid is a circular double-stranded DNA molecule associated with cellular histones. Virions have a sedimentation coefficient (S20,w) of approximately 300S and a buoyant density of approximately 1.34–1.35 g/cm³ in cesium chloride (ICTV, 2018).

Conclusion

Microscopically, proliferative and degenerative changes in keratinocytes were observed, with acanthosis, vacuolation, and changes that became progressively more evident in the superficial epidermal layers.

Ultrastructurally, nuclear and cytoplasmic changes, vacuolation, modifications of tonofibrils, desmosomes, and intercellular cohesion, and structures morphologically resembling viral particles were observed, mainly in the more differentiated epidermal layers.

These findings are compatible with the possible involvement of papillomavirus in the pathogenesis of the lesions, although confirmation of their viral nature and determination of the BPV type involved depend on the use of specific methods, such as molecular or immunohistochemical techniques.

Agriculture Journal IJOEAR Call for Papers

References
  1. Almeida, J. D., Howatson, A. F., & Williams, M. G. (1962). Electron microscope study of human warts: Sites of virus production and nature of the inclusion bodies. Journal of Investigative Dermatology, *38*, 337-345.
  2. Barthold, S. W., Koller, M. D., Olson, C., Studer, E., & Holtan, A. (1974). Atypical warts in cattle. Journal of the American Veterinary Medical Association, *165*, 276-280.
  3. Brobst, D., & Hinsman, E. (1966). Electron microscopy of the bovine cutaneous papilloma. Veterinary Pathology, *3*, 196-207.
  4. Cappellaro, C. E. M. P. M., Ribeiro, L. O. C., Mueller, S. B. K., & Piegas, N. S. (1978). Estudos da morfologia e histopatologia de diferentes tipos de papilomas bovinos. Biológico, *44*, 307-316.
  5. Catroxo, M. H. B., Martins, A. M. C. R. P. F., Petrella, S., Souza, F., & Nastari, B. D. B. (2013). Ultrastructural study of bovine papillomavirus during outbreaks in Brazil. International Journal of Morphology, *31*(2), 777-784.
  6. Chapman, G. B., Drusin, L. M., & Todd, J. E. (1963). Fine structure of the human wart. American Journal of Pathology, *42*, 619-629.
  7. Ciuffo, G. (1907). Innesto positivo com filtrado de verruga volgare. Giornale Italiano di Malattie Veneree, *48*, 12-17.
  8. Creech, G. T. (1929). Experimental studies of the etiology of common warts in cattle. Journal of Agricultural Research, *39*, 723-737.
  9. Figueirêdo, P., Santos, G. F., Oliveira, L. B., Santos, L. A. B., Barreto, D. M., Candido, A. L., Campos, A. C., Azevedo, E. O., & Batista, M. V. (2020). High genotypic diversity, putative new types and intra-genotype variants of bovine papillomavirus in Northeast Brazil. Pathogens, *9*(9), 748.
  10. Fujimoto, Y., & Olson, C. (1966). The fine structure of the bovine wart. Pathologia Veterinaria, *3*, 659-684.
  11. Heliad, H. A. (1934). Les papillomes bovins [Doctoral thesis, École Nationale Vétérinaire d'Alfort].
  12. International Committee on Taxonomy of Viruses. (2018). Family: Papillomaviridae (ICTV Report).
  13. Jelínek, F., & Tachezy, R. (2005). Cutaneous papillomatosis in cattle. Journal of Comparative Pathology, *132*, 70-81.
  14. Jarrett, W. F. H., Campo, M. S., Oweil, B. E., Laird, H. M., & Coggins, L. W. (1984). A novel bovine papillomavirus (BPV-6) causing true epithelial papillomas of the mammary gland skin: A member of a proposed new BPV subgroup. Virology, *136*(2), 255-264.
  15. Junqueira, L. C., & Carneiro, J. (2013). Histologia básica: Texto e atlas (12th ed.). Guanabara Koogan.
  16. Koller, L. D., & Olson, C. (1972). Attempted transmission of warts from man, cattle, and horses and deer fibroma to selected hosts. Journal of Investigative Dermatology, *58*, 366-368.
  17. Lalrinkima, Shafiqur Rahman, Aditya Sharma, Kabal Singh Brar, & Shagufta Azmi. (2022). Pathomorphological study on bovine papilloma: A case report. Pharma Innovation, 408-409.
  18. Lancaster, W. D., & Olsen, C. (1982). Animal papillomaviruses. Microbiological Reviews, *46*, 191-207.
  19. Lee, K. P., & Olson, C. (1969). Histochemical studies of experimentally produced bovine fibropapillomas. Journal of Investigative Dermatology, *52*, 454-464.
  20. Lin, Y., Liu, W., Jiang, J., Rai, K. R., & Che, Y. (2026). Genomic characterization of a Chinese bovine papillomavirus isolate and its L1-based phylogenetic placement in a global dataset. Frontiers in Veterinary Science, *13*(1839050).
  21. Magalhaes, O. (1920). Verruga dos bovídeos. Brasil Médico, *34*, 430.
  22. Marques, J. R. F., & Cardoso, L. S. (1997). A bubalinocultura no Brasil e no mundo. In O búfalo no Brasil: Anais do Simpósio Brasileiro de Bubalinocultura (pp. 7-42). UFBA, Escola de Agronomia.
  23. Matoltsy, A. G. (1975). Desmosomes, filaments and keratohyaline granules: Their role in the stabilization and keratinization of the epidermis. Journal of Investigative Dermatology, *65*, 127-142.
  24. Medeiros-Fonseca, B., Abreu-Silva, A. L., Medeiros, R., Oliveira, P. A., & Costa, R. M. G. (2021). Pteridium spp. and bovine papillomavirus: Partners in cancer. Frontiers in Veterinary Science, *8*(758720), 1-9.
  25. Munday, J. S. (2018). Bovine and human papillomaviruses: A comparative review. Veterinary Pathology, *51*, 1063-1075.
  26. Naffa, R., Maidment, C., Ahn, M., Ingham, B., Hinkley, S. F. R., & Norris, G. E. (2019). Molecular and structural insights into skin collagen reveals several factors that influence its architecture. International Journal of Biological Macromolecules, *128*, 509-520.
  27. Njoku, C. O., & Burwash, W. A. (1972). Congenital cutaneous papilloma in a foal. Cornell Veterinarian, *62*(1), 54-57.
  28. Olson, C. (1963). Cutaneous papillomatosis in cattle and other animals: Transmissible and viral tumors. Annals of the New York Academy of Sciences, *108*, 1042-1056.
  29. Olson, C., Segre, D., & Skidmore, L. (1960). Further observations on immunity to bovine cutaneous papillomatosis. American Journal of Veterinary Research, *21*, 233-242.
  30. Reynolds, E. S. (1963). The use of lead citrate at high pH as an electron-opaque stain in electron microscopy. Journal of Cell Biology, *7*(1), 208-212.
  31. Roperto, S., Russo, V., Ozkul, A., Sepici-Dicel, A., Maiolino, P., Borzacchiello, G., Marcus, I., Esposito, I., Riccardi, M. G., & Roperto, F. (2013). Bovine papillomavirus type 2 infects the urinary bladder of water buffalo (Bubalus bubalis) and plays a crucial role in bubaline urothelial carcinogenesis. Journal of General Virology, *94*(2), 403-408.
  32. Rosemberg, G. (1940). Leather defects due to papillomatosis in cattle. Deutsche Tierärztliche Wochenschrift, *48*, 636-637.
  33. Russo, V., Roperto, F., De Biase, D., Cerino, P., Urraro, C., Munday, J. S., & Roperto, S. (2020). Bovine papillomavirus type 2 infection associated with papillomatosis of the amniotic membrane in water buffaloes (Bubalus bubalis). Pathogens, *9*(262), 1-15.
  34. Silvestre, O., Borzacchiello, G., Nava, D., Iovane, G., Russo, V., Vecchio, D., D'Ausilio, F., Gault, D. A., Campo, M. S., & Paciello, O. (2009). Bovine papillomavirus type 1 DNA and E5 oncoprotein expression in water buffalo fibropapillomas. Veterinary Pathology, *46*(4), 636-641.
  35. Shope, R. E. (1933). Infectious papillomatosis of rabbits with a note on histopathology. Journal of Experimental Medicine, *88*, 607-624.
  36. Somvanshi, R., Koul, G., Sharma, B., & Biswas, J. (1986). Clinico-pathological observations on cutaneous bovine papillomas. Indian Journal of Animal Sciences, *56*, 836-840.
  37. Sousa, F. A., Daudt, C., Lins, A. M. C., Santos, I. R., Tomaya, L. Y. C., Lima, A. S., Reis, E. M. B., Satrapa, R. A., Driemeyer, D., Bagon, A., Canal, C. W., Salvarani, F. M., & Silva, F. R. C. (2025). Characterization of papillomatous lesions and genetic diversity of bovine papillomavirus from the Amazon Region. Viruses, *17*(5), 719.
  38. Strauss, M. J., Shaw, E. W., Buting, H., & Melnich, J. L. (1949). Crystalline virus like particles from skin papillomas characterized by intranuclear inclusion bodies. Proceedings of the Society for Experimental Biology and Medicine, *72*, 46-50.
  39. Studdert, M. J., McCoy, K., Allworth, M. B., & Staples, P. (1988). Papilloma of the ears of calves following tattooing. Australian Veterinary Journal, *65*, 399.
  40. Wosiacki, S. R., Claus, M. C., Alfieri, A. F., & Alfieri, A. A. (2006). Bovine papillomavirus type 2 detection in the urinary bladder of cattle with chronic enzootic haematuria. Memórias do Instituto Oswaldo Cruz, *101*(6), 635-638.
  41. Watson, M. L. (1958). Staining of tissue sections for electron microscopy with heavy metals. Journal of Biophysical and Biochemical Cytology, *4*, 475-478.
