Outbreak of Cutaneous Papillomatosis in Buffaloes (Bubalus bubalis): Diagnosis by Transmission Electron Microscopy

Authors: Cappellaro, C.E.M.P.D.M; Catroxo, M.H.B.; Martins, A.M.C.R.P.F.
Outbreak of Cutaneous Papillomatosis in Buffaloes (Bubalus bubalis): Diagnosis by Transmission Electron Microscopy
DOI
10.25125/ijoear-aug-2026-28
DIN
IJOEAR-AUG-2026-28
Abstract

Papillomatosis is an emerging infectious disease that causes significant economic losses in intensive and semi-intensive buffalo production systems. In dairy herds, the disease impairs milking, causes cutaneous lesions and bleeding, and predisposes animals to mastitis. In beef production systems, the main impacts include reduced weight gain, hide damage, and increased veterinary care costs. The disease may occur in cutaneous and mucosal forms. The cutaneous form is characterized by the presence of warts or fibropapillomas distributed throughout different regions of the body, whereas the mucosal form is associated with bovine enzootic hematuria and urinary bladder carcinogenesis. The lesions observed include papillomas, fibropapillomas, and fibromas, as well as verrucous lesions affecting the mucosa of the rumen, oral cavity, esophagus, and amniotic membrane. Transmission occurs mainly from animal to animal and is facilitated by injuries to the skin and mucous membranes caused by fences, water troughs, feeding troughs, or instruments used for animal restraint. Bovine papillomaviruses are double-stranded DNA viruses belonging to the family Papillomaviridae. In 1993, fibropapilloma samples from five buffaloes (Bubalus bubalis) originating from a farm located in the municipality of Registro, São Paulo State, Brazil, were submitted to the Electron Microscopy Laboratory of the Biological Institute, São Paulo, Brazil. The samples were processed using transmission electron microscopy, negative staining, and resin embedding techniques. In all samples, a large number of non-enveloped papillomavirus particles with icosahedral symmetry were observed. These particles were characterized as "full" and "empty" virions, measuring approximately 60 nm in diameter. In ultrathin sections of papilloma fragments, intracytoplasmic viral particles measuring approximately 30 nm in diameter were observed, associated with thickening of the plasma membrane, which exhibited a serrated appearance. In addition, intranuclear viral particles and membrane-bound intracytoplasmic vacuoles were identified. In the reticular layer, a nucleus with an irregular contour, marginalized chromatin, and the presence of viral particles was observed. The results confirm the occurrence of papillomatosis in buffaloes and demonstrate the importance of electron microscopy for the rapid diagnosis and morphological characterization of the viral agent.

Keywords
Papillomatosis Buffaloes Transmission electron microscopy.
Download Options
Download Full PDF
Share Article
Facebook Twitter LinkedIn
Introduction

Bovine papillomatosis is an infectious disease of viral origin caused by bovine papillomavirus (BPV). Although it is more frequently described in cattle, it also affects buffaloes, in which it may occur in both cutaneous and mucosal forms. The cutaneous form is characterized by the presence of warts or fibropapillomas distributed across various regions of the body, including the head, neck, back, ears, abdomen, gluteal region, teats, udder, vulva, and perivulvar area (Silvestre et al., 2009). These tumors, which may occur as single or multiple lesions of varying sizes, tend to develop more frequently in previously traumatized areas, possibly due to the release of inflammatory cytokines, reactivation of latent viral infections, and stimulation of cellular proliferation (Silvestre et al., 2009; Al-Redah et al., 2021).

The mucosal form of the disease, mainly associated with BPV-2, is related to bovine enzootic hematuria and urinary bladder carcinogenesis in adult animals grazing on pastures containing bracken fern (Pteridium aquilinum). This condition results from a synergistic interaction between the virus and carcinogenic compounds present in the plant. In buffaloes, this form has been reported in both Brazil and Italy (Maiolino et al., 2013; Roperto et al., 2013; Rocha et al., 2022).

In Brazil, cutaneous papillomatosis was first described in buffaloes in 1993 in females raised in the municipality of Registro, São Paulo State, through transmission electron microscopy and histopathological analyses (Cappellaro et al., 1993; Cappellaro, 1994). Subsequently, cases have been reported in several countries, including Italy, Iraq, Turkey, India, Mexico, and Brazil, and have been more commonly observed in adult animals, although occasional cases have been described in young individuals (Singh et al., 2010). Transmission occurs mainly from buffalo to buffalo, without the need for an intermediate bovine host, and is facilitated by injuries to the skin and mucous membranes caused by fences, water troughs, feeding troughs, or instruments used for animal restraint (Somvanshi, 2011). In addition to horizontal transmission, vertical transmission has also been reported (Russo et al., 2017). Different types of lesions may be observed, including papillomas, fibropapillomas, and fibromas (Jangir et al., 2017), as well as verrucous lesions affecting the mucosa of the rumen, oral cavity, and esophagus (Kumar et al., 2012), and even the amniotic membrane (Russo et al., 2020).

Conclusion

This study confirms the occurrence of cutaneous papillomatosis in buffaloes in Brazil and demonstrates the utility of transmission electron microscopy for the rapid diagnosis and morphological characterization of bovine papillomavirus. The ultrastructural findings, including the visualization of non-enveloped, icosahedral viral particles with "full" and "empty" virions (45–55 nm), as well as intracytoplasmic and intranuclear viral particles (30 nm) and associated cellular alterations (serrated membranes, irregular nuclei with marginalized chromatin), provide detailed morphological evidence of papillomavirus infection in buffalo cutaneous fibropapillomas.

The results highlight the importance of electron microscopy as a diagnostic tool for emerging viral diseases in livestock. The high detection rate (100%) and the characteristic ultrastructural features confirm the presence of papillomavirus in the examined samples and contribute to the understanding of the pathogenesis of cutaneous papillomatosis in buffaloes.

Overall, this study provides valuable baseline information on the ultrastructural features of papillomavirus in buffaloes and emphasizes the need for integrated diagnostic approaches combining electron microscopy, histopathology, and molecular techniques for effective disease surveillance and control.

Agriculture Journal IJOEAR Call for Papers

References
  1. Al-Redah, S. A. A., Mansour, K. A., & Al-nakeeb, N. K. M. (2021). Histomorphological and molecular study of warts in Iraqi buffalo. Veterinary Practitioner, *22*(2), 152-155.
  2. Bocaneti, F., Altamura, G., Corteggio, A., Velescu, E., Roperto, F., & Borzacchiello, G. (2016). Bovine papillomavirus: New insights into an old disease. Transboundary and Emerging Diseases, *63*(1), 14-23.
  3. Borzacchiello, G., & Roperto, F. (2008). Bovine papillomaviruses, papillomas and cancer in cattle. Veterinary Research, *39*, 45.
  4. Brenner, S., & Horne, R. W. (1959). A negative staining method for high resolution electron microscopy of viruses. Biochimica et Biophysica Acta, *34*, 103.
  5. Buff Jr., W., Mueller, S. B. K., Cappellaro, C. E. M. P. D. M., Catroxo, M. H. B., & Esteves, R. (1988). Estudo de papilomatose cutânea de bovinos – ocorrência atípica em cão. Revista Brasileira de Medicina Veterinária, *10*, 33-36.
  6. Cappellaro, C. E. M. P. D. M., Baruselli, P. S., Catroxo, M. H. B., & Mueller, S. B. K. (1993). Visualização de partículas semelhantes à vírus em papiloma cutâneo de búfalos. In XIV Colóquio da Sociedade Brasileira de Microscopia Eletrônica (Vol. I, pp. 293-294). Caxambu, MG, Brazil.
  7. Cappellaro, C. E. M. P. D. M. (1994). Aspectos histopatológicos e ultraestruturais de papilomatose cutânea em búfalos (Bubalus bubalis, Linnaeus, 1758) [Master's thesis, Universidade Federal de São Paulo].
  8. Catroxo, M. H. B., Martins, A. M. C. R. P. F., Petrella, S., Souza, F., & Nastari, B. D. B. (2013). Ultrastructural study of bovine papillomavirus during outbreaks in Brazil. International Journal of Morphology, *31*(2), 777-784.
  9. DiMaio, D., & Petti, L. M. (2013). The E5 proteins. Virology, *445*, 99-114.
  10. Dileepkumar, K. M., & Ansari, M. (2012). Clinico-therapeutic management of cutaneous papillomatosis in a buffalo calf. Intas Polivet, *13*(1), 67-69.
  11. Doorbar, J., Quint, W., Banks, L., Bravo, I. G., Stoler, M., Broker, T. R., & Stanley, M. A. (2012). The biology and life-cycle of human papillomaviruses. Vaccine, *30*(Suppl. 5), F55-F70.
  12. Elghmry, Z. M., Mohammed, N., Korashy, E., Ghonaim, A. H., & Li, W. (2025). Bovine papillomavirus: The silent threat in cattle health. In L. Wang (Ed.), Veterinary virology of domestic and pet animals. Springer Nature.
  13. Freitas, A. C., Silva, M. A. R., Jesus, A. L. S., Mariz, F. C., Cordeiro, M. N., Albuquerque, B. M. F., & Batista, M. V. A. (2011). Recent insights into bovine papillomavirus. African Journal of Microbiology Research, *5*(33), 6004-6012.
  14. Gentile, M., & Gelderblom, H. R. (2014). Electron microscopy in rapid viral diagnosis: An update. New Microbiologica, *37*, 403-422.
  15. Ghim, S., Newsome, J., Bell, J., Sundberg, J. P., Schlegel, R., & Jenson, A. B. (2000). Spontaneously regressing oral papilloma induce systemic antibodies that neutralize canine oral papilloma virus. Experimental and Molecular Pathology, *68*, 147-151.
  16. Goldsmith, C. S., & Miller, S. E. (2009). Modern uses of electron microscopy for detection of viruses. Clinical Microbiology Reviews, *22*(4), 552-563.
  17. Gonzales-Santander, R. (1969). Técnicas de microscopia eletrônica em biología. Aguilar.
  18. Hazelton, P. R., & Gelderblom, H. R. (2003). Electron microscopy for rapid diagnosis of emerging infectious agents. Emerging Infectious Diseases, *9*(3), 294-303.
  19. Ingle, A., Guim, S., Joh, J., Chepkoech, I., Jenson, A. B., & Sundberg, J. P. (2011). Novel laboratory mouse papillomavirus (MusPV) infection. Veterinary Pathology, *48*(2), 500-505.
  20. Jangir, B. L., Bind, R. B., Kumar, P., & Somvanshi, R. (2017). Pathological studies and detection of different bovine papilloma virus types in buffalo cutaneous warts. Turkish Journal of Veterinary and Animal Sciences, *41*, 306-311.
  21. Jelínek, F., & Tachezy, R. (2005). Cutaneous papillomatosis in cattle. Journal of Comparative Pathology, *132*, 70-81.
  22. Joshi, D. V., Patel, B. J., & Sharma, S. N. (1994). Fibropapilloma of mammary gland in a buffalo calf. Indian Journal of Veterinary Pathology, *18*, 61-62.
  23. Kavithaa, N. V., Rajkumar, N. V., & Jiji, R. S. (2014). Papillomatosis in Jersey cows and its different medical treatment. International Journal of Science, Environment and Technology, *3*(2), 692-694.
  24. Kumar, P., Nagarajan, N., Saikumar, G., Arya, R. S., & Somvanshi, R. (2015). Detection of BPV one papilloma viruses in wart-like lesions of upper gastrointestinal tract of cattle and buffaloes. Transboundary and Emerging Diseases, *62*, 264-271.
  25. Lalrinkima, S. R., Sharma, A., Brar, K. S., & Azmi, S. (2022). Pathomorphological study on bovine papilloma: A case report. Pharma Innovation Journal, *11*(11), 408-409.
  26. Leishangthem, G. D., Somvanshi, R., & Tiwari, A. K. (2008). Detection of bovine papillomaviruses in cutaneous warts/papillomas in cattle. Indian Journal of Veterinary Pathology, *32*, 15-20.
  27. Luft, J. H. (1961). Improvements in epoxy resin embedding methods. Journal of Biophysical and Biochemical Cytology, *9*, 409-414.
  28. Maeda, Y., Shibahara, T., Wada, Y., Kadota, K., Kanno, T., Uchida, I., & Hatama, S. (2007). An outbreak of teat papillomatosis in cattle caused by bovine papilloma virus (BPV) type 6 and unclassified BPVs. Veterinary Microbiology, *121*, 242-248.
  29. Maiolino, P., Özkul, A., Sepici-Dincel, A., Roperto, F., Yücel, G., Russo, V., Urraro, E. C., Lucà, R., Riccardi, M. G., Martano, M., Borzacchiello, G., Esposito, I., & Roperto, S. (2013). Bovine papillomavirus type 2 infection and microscopic patterns of urothelial tumors of the urinary bladder in water buffaloes. BioMed Research International, *2*(937918), 1-6.
  30. Módolo, D. G., Araldia, R. P., Mazzuchelli-de-Souza, J., Pereira, A., Pimenta, D. C., Zanphorlind, L. M., Beçaka, W., Menossie, M., Stocco, R. C., & de Carvalho, R. F. (2017). Integrated analysis of recombinant BPV-1 L1 protein for the production of a bovine papillomavirus VLP vaccine. Vaccine, *35*, 1590-1593.
  31. Nasir, L., & Campo, M. S. (2008). Bovine papillomaviruses: Their role in the aetiology of cutaneous tumours of bovids and equids. Veterinary Dermatology, *19*(5), 243-254.
  32. Nooruddin, M., Singh, K. B., & Nauriyal, D. C. (1989). Cutaneous papillomatosis (warts) in buffaloes. Buffalo Bulletin, *8*, 37-42.
  33. Özmen, G., & Kale, M. (2023). Searching bovine papillomavirus presence in lesions seen on teats of cows. Pesquisa Veterinária Brasileira, *43*, e07150.
  34. Pangty, K., Singh, S., Goswami, R., Saikumar, G., & Somvanshi, R. (2010). Detection of BPV-1 and -2 and quantification of BPV-1 by real-time PCR in cutaneous warts in cattle and buffaloes. Transboundary and Emerging Diseases, *57*, 185-196.
  35. Prasad, V. D., Kumar, R. V. S., Lakshmi, N. D., Krishana, N. V. V. H., & Veena, P. (2009). An unusual case of cutaneous fibroma on the fore head region of a graded murrah she buffalo – A case report. Buffalo Bulletin, *28*(3), 119-120.
  36. Raval, S. R., Joshi, D. V., Sutariya, P., Patel, B. J., & Joshi, K. R. (2015). Fibroadenoma of mammary gland in a Meshana buffalo. Indian Journal of Veterinary Pathology, *39*(4), 347-348.
  37. Reynolds, E. S. (1963). The use of lead citrate at high pH as an electron-opaque stain in electron microscopy. Journal of Cell Biology, *17*, 208-212.
  38. Rocha, J. F., Santos, B. B. N., Galvão, A., Marques, T. O., Silva, L. R. L., França, T. N., & Peixoto, P. V. (2022). Occurrence enzootic hematuria in buffaloes in Brazil: Epidemiological, clinical, and pathological aspects. Pesquisa Veterinária Brasileira, *42*, e06875, 1-13.
  39. Rojas-Anaya, E., Cantú-Covarrubias, A., Álvarez, J. F. M., & Loza-Rubio, E. (2016). Detection and phylogenetic analysis of bovine papillomavirus in cutaneous warts in cattle in Tamaulipas, Mexico. Canadian Journal of Veterinary Research, *80*(4), 262-268.
  40. Roperto, S., Russo, V., Ozkul, A., Corteggio, A., Sepici-Dincel, A., Catoi, C., Esposito, I., Riccardi, M. G., Urraro, C., Luca, R., Ceccarelli, D. M., Longo, M., & Roperto, F. (2013). Productive infection of bovine papillomavirus type 2 in the urothelial cells of naturally occurring urinary bladder tumors in cattle and water buffaloes. PLoS ONE, *8*(5), e62227, 1-8.
  41. Russo, V., Roperto, F., De Biase, D., Cerino, P., Urraro, C., Munday, J. S., & Roperto, S. (2020). Bovine papillomavirus type II infection associated with papillomatosis of amniotic membrane in water buffaloes (Bubalus bubalis). Pathogens, *9*(262), 1-15.
  42. Savini, F., Gallina, L., Prosperi, A., Puleio, R., Lavazza, A., Di Marco, P., Tumino, S., Moreno, A., & Scagliarini, A. (2020). Bovine papillomavirus 1 gets out of the flock: Detection in an ovine wart in Sicily. Pathogens, *9*(429), 1-9.
  43. Silva, M. A. R., Lima, R. C. P., Lima, E. G., Albuquerque, B. M., Nascimento, D. G. E. G., Fernandes, L. H., & Freitas, A. C. (2026). Gene expression, viral load, and bovine papillomavirus coinfection in blood and cutaneous warts of cattle. Brazilian Journal of Microbiology, *57*(41), 1-9.
  44. Silvestre, O., Borzacchiello, G., Nava, D., Iovane, G., Russo, V., Vecchio, D., D'Ausilio, F., Gault, E. A., Campo, M. S., & Paciello, O. (2009). Bovine papillomavirus type 1 DNA and E5 oncoprotein expression in water buffalo fibropapillomas. Veterinary Pathology, *46*, 636-641.
  45. Singh, R., & Mouli, S. P. (1990). Animal neoplasm recorded in Andhra Pradesh. Indian Journal of Veterinary Pathology, *14*, 65-67.
  46. Singh, V., Somvanshi, R., Yasotha, T., Subodh, S. K., Singh, S. K., & Dayal, S. (2010). Detection of BPV-2 in cutaneous warts of Indian water buffaloes (Bubalus bubalis). Buffalo Bulletin, *29*(2), 133-140.
  47. Somvanshi, R. (2011). Papillomatosis in buffaloes: A less-known disease. Transboundary and Emerging Diseases, *58*, 327-332.
  48. van DyK, E., Bosman, A.-M., van Wilpe, E., Williams, J. H., Bengis, R. G., van Heerden, J., & Venter, E. H. (2011). Detection and characterisation of papillomavirus in skin lesions of giraffe and sable antelope in South Africa. Journal of the South African Veterinary Association, *82*(2), 80-85.
  49. Vrablikova, A., Brezani, V., Psikal, I., Fraiberk, M., Sebela, M., Fojtikova, M., Kulich, P., Hezova, R., & Masek, J. (2023). Development of modern immunization agent against bovine papillomavirus type 1 infection based on BPV1 L1 recombinant protein. Frontiers in Veterinary Science, *10*, 1116661, 1-7.
  50. Watson, M. L. (1958). Staining of tissue sections for electron microscopy with heavy metals. Journal of Biophysical and Biochemical Cytology, *4*, 475-478.
  51. Williams, J. H., Van Dik, E., Nel, P., Lane, E., Van Wilpe, E., Bengis, R. G., Klerk-Lorist, L.-M., & van Heerden, J. (2011). Pathology and immunohistochemistry of papillomavirus-associated cutaneous lesions in Cape mountains zebra, giraffe, sable antelope and African buffalo in South Africa. Journal of the South African Veterinary Association, *82*(2), 97-106.
